Color blending functions in VEX

calendar_today

28.11.2022

label

VEX, Texturing

mouse

Houdini 19.5

Description

Functions for blending colors and image layers.

1 Functions

Functions for blending two color vectors 'target' and 'blend'. Original code by ridhojeftha: https://www.shadertoy.com/view/4tSGWV

CPP
        //Darken
vector darken(vector target, blend){
    return min(target, blend);
}

//Multiply
vector multiply(vector target, blend){
    return target * blend;
}

//Color Burn
vector color_burn(vector target, blend){
    return 1.0 - (1.0 - target)/ blend;
}

//Linear Burn
vector linear_burn(vector target, blend){
    return target + blend - 1.0;
}

//Lighten
vector lighten(vector target, blend){
    return max (target, blend);
}

//Screen
vector screen(vector target, blend){
    return 1.0 - (1.0 - target) * (1.0 - blend);
}

//Color Dodge
vector color_dodge(vector target, blend){
    return target / (1.0 - blend);
}

//Linear Dodge
vector linear_dodge(vector target, blend){
    return target + blend;
}

//Overlay
vector overlay(vector target, blend){
    vector temp;
    temp.x = (target.x > 0.5) ? (1.0-(1.0-2.0*(target.x-0.5))*(1.0-blend.x)) : (2.0*target.x)*blend.x;
    temp.y = (target.y > 0.5) ? (1.0-(1.0-2.0*(target.y-0.5))*(1.0-blend.y)) : (2.0*target.y)*blend.y;
    temp.z = (target.z > 0.5) ? (1.0-(1.0-2.0*(target.z-0.5))*(1.0-blend.z)) : (2.0*target.z)*blend.z;
    return temp;
}

//Soft Light
vector soft_light(vector target, blend){
    vector temp;
    temp.x = (blend.x > 0.5) ? (1.0-(1.0-target.x)*(1.0-(blend.x-0.5))) : (target.x * (blend.x + 0.5));
    temp.y = (blend.y > 0.5) ? (1.0-(1.0-target.y)*(1.0-(blend.y-0.5))) : (target.y * (blend.y + 0.5));
    temp.z = (blend.z > 0.5) ? (1.0-(1.0-target.z)*(1.0-(blend.z-0.5))) : (target.z * (blend.z + 0.5));
    return temp;
}

//Hard Light
vector hard_light(vector target, blend){
    vector temp;
    temp.x = (blend.x > 0.5) ? (1.0-(1.0-target.x)*(1.0-2.0*(blend.x-0.5))) : (target.x * (2.0*blend.x));
    temp.y = (blend.y > 0.5) ? (1.0-(1.0-target.y)*(1.0-2.0*(blend.y-0.5))) : (target.y * (2.0*blend.y));
    temp.z = (blend.z > 0.5) ? (1.0-(1.0-target.z)*(1.0-2.0*(blend.z-0.5))) : (target.z * (2.0*blend.z));
    return temp;
}

//Vivid Light
vector vivid_light(vector target, blend){
    vector temp;
    temp.x = (blend.x > 0.5) ? (1.0-(1.0-target.x)/(2.0*(blend.x-0.5))) : (target.x / (1.0-2.0*blend.x));
    temp.y = (blend.y > 0.5) ? (1.0-(1.0-target.y)/(2.0*(blend.y-0.5))) : (target.y / (1.0-2.0*blend.y));
    temp.z = (blend.z > 0.5) ? (1.0-(1.0-target.z)/(2.0*(blend.z-0.5))) : (target.z / (1.0-2.0*blend.z));
    return temp;
}

//Linear Light
vector linear_light(vector target, blend){
    vector temp;
    temp.x = (blend.x > 0.5) ? (target.x)+(2.0*(blend.x-0.5)) : (target.x +(2.0*blend.x-1.0));
    temp.y = (blend.y > 0.5) ? (target.y)+(2.0*(blend.y-0.5)) : (target.y +(2.0*blend.y-1.0));
    temp.z = (blend.z > 0.5) ? (target.z)+(2.0*(blend.z-0.5)) : (target.z +(2.0*blend.z-1.0));
    return temp;
}

//Pin Light
vector pin_light(vector target, blend){
    vector temp;
    temp.x = (blend.x > 0.5) ? (max (target.x, 2.0*(blend.x-0.5))) : (min(target.x, 2.0*blend.x));
    temp.y = (blend.y > 0.5) ? (max (target.y, 2.0*(blend.y-0.5))) : (min(target.y, 2.0*blend.y));
    temp.z = (blend.z > 0.5) ? (max (target.z, 2.0*(blend.z-0.5))) : (min(target.z, 2.0*blend.z));
    return temp;
}

//Difference
vector difference(vector target, blend){
    return abs(target - blend);
}

//Exclusion
vector exclusion(vector target, blend){
    return 0.5 - 2.0*(target-0.5)*(blend-0.5);
}

//Subtract
vector subtract(vector target, blend){
    return target - blend;
}

//Divide
vector divide(vector target, blend){
    return target / blend;
}
